– 15” LCD Screen Controller.
– Pre-Install tungsten hard metal control circuit, 30% less electrode loss.
– Adopting Fuzzy control theory, carbon deposition can be checked by itself.
– On the time of unstable discharge, the machine have auto alert system.
– From rough processing to fine processing can be finished at one time.
– Expert data system, simple operating for beginners.
– Oil Level control, process device will be stopped automatically.
– Accelerograph control, if the display is OFF, devices will be stopped automatically.
– If temperature of working fluid is too high, the process will be cut off automatically.
– Temperature induction. Fire alert and cut off the power supply at the same time.
– Machine is designed by computer analysis with good structure and high precision.
– Good precision screw and DC/AC servo motor are used in Z axis.
– High precision bearing and high precision ball screw are used in X,Y, axis.
ESPECIFICACIONES
Table Size
(mm)
700 X 400
Working Slot
(mm)
1200X620X450
Maximum Oil Level
(mm)
300
Longitudinal X Travel
(mm)
450
Lateral Y Travel
(mm)
350
Vertical Travel Z
(mm)
200
Auxiliary (2nd Axis) travel | 200 mm |
Maximum distance from work table to electrode head | 520 mm |
Maximum electrode weight | 80 kg |
Maximum working weight | 1000 kg |
Machine weight | 2000 kg |
Packing size | 1900x1500x2200 mm |
Max working current | 75 A |
Max speed | 1200x620x450 mm3/min |
Power consumption | 6 kW |
Surface Roughness | 0.2% μm |
